24V Addressable 60 LED RGB DMX LED Tape
Model:
DMX-60 RGB 24V
Categories Colorful Strip Lights, DMX LED Strip Lights
Tags 10mm, 24V, Bendable, Continuous, Cuttable, Cutting, Dimmable, DMX, DMX512, Flexible, IP65, IP67, IP68, RGB, SMD, SMD 5050, SMD5050, Waterproof
Highlights
→ Flexible,Bendable,Cuttable
→ RGB Colorful
→ DMX512 Controller
→ Waterproof IP65, IP67 or IP68
→ 3M Stick for Easy Installation
SKU
DMX-60 RGB 24V
Category: Colorful Strip Lights, DMX LED Strip Lights
Tags: 10mm, 24V, Bendable, Continuous, Cuttable, Cutting, Dimmable, DMX, DMX512, Flexible, IP65, IP67, IP68, RGB, SMD, SMD 5050, SMD5050, Waterproof
Item NO. | DMX-60 RGB 24V IP40/IP65/IP67/IP68 | ||
Light Colour | RGB Colorful | ||
Input Voltage | 12VDC | Light Source | 60 SMD 5050 / M |
Power Consumption | 14.4W/ M | CRI | RGB Colorful |
Pixel | 10 Pixels / M | PCB Color |
White/Black |
Brightness | 600-1000LM/M | Beam Angle | 120° |
Average Lifetime | 50,000 hours | Working Temperature | -20 – 50°C |
Cut Length | 99.24mm | Type | DMX512 Protocal |
IP Rating | IP40 / IP65 / IP67 / IP68 | ||
Dimmable | Yes Support with DMX 512 RGB Controller |
||
Width | W= 12mm | ||
Length | Standard 5 meters as a roll. Any length can be Customized | ||
Cable | 15cm cable for input.(Any connector cables can be customized) | ||
Connection | DC+: connect to power supply DC+ DMX+ (A): connect to controller DMX+ (A) DMX- (B): connect to controller DMX- (B) GND: connect to power supply GND & controller GND |
||
Power Supply |
Choose Suitable 24VDC Power Supply. | ||
Controller | Choose Suitable RGB DMX512 Controller | ||
Address Writer |
Choose Suitable RGB DMX512 Address Writer | ||
Stick | Standard is 3M Yellow Stick(3M Red Stick can be option) |
Send Your Inquiry
Specifications
Item NO. | DMX-60 RGB 24V IP40/IP65/IP67/IP68 | ||
Light Colour | RGB Colorful | ||
Input Voltage | 12VDC | Light Source | 60 SMD 5050 / M |
Power Consumption | 14.4W/ M | CRI | RGB Colorful |
Pixel | 10 Pixels / M | PCB Color |
White/Black |
Brightness | 600-1000LM/M | Beam Angle | 120° |
Average Lifetime | 50,000 hours | Working Temperature | -20 – 50°C |
Cut Length | 99.24mm | Type | DMX512 Protocal |
IP Rating | IP40 / IP65 / IP67 / IP68 | ||
Dimmable | Yes Support with DMX 512 RGB Controller |
||
Width | W= 12mm | ||
Length | Standard 5 meters as a roll. Any length can be Customized | ||
Cable | 15cm cable for input.(Any connector cables can be customized) | ||
Connection | DC+: connect to power supply DC+ DMX+ (A): connect to controller DMX+ (A) DMX- (B): connect to controller DMX- (B) GND: connect to power supply GND & controller GND |
||
Power Supply |
Choose Suitable 24VDC Power Supply. | ||
Controller | Choose Suitable RGB DMX512 Controller | ||
Address Writer |
Choose Suitable RGB DMX512 Address Writer | ||
Stick | Standard is 3M Yellow Stick(3M Red Stick can be option) |
Send Your Inquiry
